QS7AA030M AC Servo Driver | £255 + VAT
QS7AA030M is a universal servo drive product based on QS6 optimization and improvement, adhering to the Adtech QS6 series of excellent quality, more stable and more convenient. The QS7AA030M servo motor drive are more mature and stable with rich and complete data. New adding 485 communication function makes to connect with the upper computer software or controller more convenient and reliable.
£255.00
Prices are NOT inclusive of VAT
- The characteristics of last generation QS6 servo drivers have been fully retained.
- AC sine wave control, smooth torque, no impulse.
- 2500 line incremental photoelectric encoder, high positional accuracy, rotation positional accuracy can reach 1/10000R.
- Speed ration can be as large as 1:5000, has stable torque characteristics from low speed to high speed.
- Adopting high speed FPGA processing, motor fastest rotation speed can be 5000RPM.
- Rich and complete parameter setting can be configured with different ways of working and operating characteristics to adapt to different requirements.
- Possess position, speed and torque control mode, has applications in a wide range.
- Use intelligent Space Vector control (SVPWM), has much larger torque and much less noise than traditional SPWM.
- Up to three times overload design, stronger load ability.
- Perfect protection function: over current, overvoltage, over heat, encoder abnormal etc.
- Perfect condition monitoring function, such as positional deviation, rotate speed, feedback impulse, command impulse etc.
Input Voltage
AC220V -15%～+10%
Driver Current
30A
Matching Motor
750W~1500W motor
Using Temperature
Working environment temperature：45℃
Storage environment temperature：-40℃～55℃
Relative Humidity
40%~80% (none condensing)
Atmosphere
86-106kpa
Control Mode
①Position control ②JOG control ③Speed control ④Torque control ⑤Position and speed control ⑥Inside pulse control ⑦Electric tool carrier control
Pulse Command
①Pulse+ Direction ②CW + CCW Pulse ③ Two-phase AB orthogonal pulses
Control Precision
0.01%
Response Frequency
≤200Hz
Pulse Frequency
≤500kHz
Speed Ratio
1：5000
Regenerative Brake
Internally Installed
Electronic Gear
1/30000～30000/1
Overload Capacity
≤300%
Feedback Pulse
2500p/r, frequency division can be set arbitrary within 0-128
Display Function
Rotate speed, motor current, motor torque, current location、positional deviation, command impulse count, current pulse frequency, space rate, I/O diagnose, analog input values, etc
Protection Function
Over current, overvoltage, low voltage, overload, over heat, lack phase, over speed, ncoder abnormal, out of tolerance, mode abnormal alarm etc.
